General Purpose Rescue Dummy - 5kg - 100 kg

10 different sizes & weights (baby 5kg up to 90kg adult)

The General Purpose training dummies are our most popular models for the common rescue scenarios such as working at height, confined space, USAR, RTA etc and general handling exercises.


Buying Options

Image Name SKU
General Duty Rescue Dummy - 10kg General Duty Rescue Dummy - 10kg
Toddler - 90cm
RLN10
General Duty Rescue Dummy - 20kg General Duty Rescue Dummy - 20kg
Adult - 180cm
RLN20A
General Duty Rescue Dummy - 20kg General Duty Rescue Dummy - 20kg
Youth - 130cm
RLN20
General Duty Rescue Dummy - 30kg General Duty Rescue Dummy - 30kg
Adult - 180cm
RLN30
General Duty Rescue Dummy - 50kg General Duty Rescue Dummy - 50kg
Adult PLUS - 180cm
RLN50
General Duty Rescue Dummy - 5kg General Duty Rescue Dummy - 5kg
Baby - 70cm
RLN5
General Duty Rescue Dummy - 70kg General Duty Rescue Dummy - 70kg
Adult - 180cm
RLN70
General Duty Rescue Dummy - 80kg General Duty Rescue Dummy - 80kg
Adult - 180cm
RLN80
General Duty Rescue Dummy - 90kg General Duty Rescue Dummy - 90kg
Adult - 180cm
RLN90
General Purpose Rescue Dummy - 100kg General Purpose Rescue Dummy - 100kg
(Drop Test) - Adult
RLN100

The General Duty dummies are our most popular models for the common rescue scenarios such as height, confined space, USAR, RTA etc, and general handling exercises.

They are weighted to produce an anatomically correct weight distribution and the 'feel' of an unconscious patient. Crucially, these dummies totally eliminate the risk of pinch welts and bruising being inflicted on trainees, a common injury when using plastic bodied dummies which usually have hard limb joints - for example when a hard knee joint folds over the forearm of a trainee. Our dummies have soft outer layers and have no hard joints - in fact, you can forcibly wrap a knee joint around a trainees forearm with no risk of injury.

Available in 10 different sizes and weights from the baby 5kg up to the very heavy 90kg Adult. We also have a special 100kg version used for drop testing of harnesses, or just if you require a really heavy dummy! The construction methods of the General Duty dummy can be seen here. These dummies are tough enough to be buried under concrete, have steel lintels, concrete slabs, trees or motor vehicles laid upon them to present realistic scenarios for rescuers. !

The protective overalls keep the dummy clean and greatly increases the lifespan. The overalls are made of a tough polyester material, (the same material as used on ballistic/stab jackets,) with high-density polypropylene webbing double stitched in the identified high-stress areas. The machine washable overalls are fitted to all sizes of the dummy. The General Duty dummies can be used in temperatures up to 100ÂșC.  Above this temperature or where 'flash-over' may occur we recommend using our Fire House flame retardant rescue dummy.

All training dummies of 20Kg and over are supplied complete with gumboots.  The boots protect the legs if the dummy is dragged along the ground. The General Duty dummy is ideally suited to either wet or dry rescue conditions. If it gets wet it needs to be hung in a dry airy place to dry before storage. All dummies are screen printed with a warning triangle, a handling risk note and space for you to record the asset number the date of purchase on the head.  These dummies have been issued with NATO stock numbers and are standard issue to armed forces around the world.

The flexible inner core is weighted to human proportions using 2kg packets of 5-10 mm crushed, washed stone aggregate. The weight packets are then sewn into a nylon inner, with all these body parts (arms, legs, chest etc) tied to the outer carcass using polypropylene rope. This method of construction prevents 'slumping' of the weight pouches and allows the dummy to maintain its shape when in use. These inner components are separated and padded using 25mm polyurethane foam contained in nylon liners which results in a dummy with the life-like feel of a real casualty.  High-density polypropylene webbing provides extra strength and durability, especially at the high-stress points.

Options available:

Size Weight Height
Baby  5 kg 70 cm
Toddler  10 kg 90 cm
Youth  20 kg 130 cm
Adult 20 kg 180 cm
Adult  30 kg 180 cm
Adult  50 kg 180 cm
Adult  50kg PLUS 180 cm
Adult  70 kg 180 cm
Adult  80 kg 180 cm
Adult  90 kg 180 cm
Adult  100 kg 180 cm
Dog 100 kg

(RLN)

  • Extra strength and durability
  • Machine-washable cotton/polyester
  • Ideally suited for predominantly dry rescue conditions
  • Supplied with gumboots/clothing

Options available:

Size Weight Height
Baby  5 kg 70 cm
Toddler  10 kg 90 cm
Youth  20 kg 130 cm
Adult 20 kg 180 cm
Adult  30 kg 180 cm
Adult  50 kg 180 cm
Adult  50kg PLUS 180 cm
Adult  70 kg 180 cm
Adult  80 kg 180 cm
Adult  90 kg 180 cm
Adult  100 kg 180 cm
Dog 100 kg
SKU RLN
Brand Ruth Lee
